Turbomolecular Pumps are designed for reliability and optimum performance in the most demanding research, industrial and analytical applications

The turbomolecular pump as first described in 1958 by Becker, was based on the older molecular drag pumps developed by Gaede in 1913, Holweck in 1923 and Siegbahn in 1944.
Turbomolecular pumps work on the principle that gas molecules can be given momentum in a desired direction by repeated collision with a moving solid surface. In a turbomolecular pump, a rapidly spinning turbine rotor 'hits' gas molecules from the inlet of the pump towards the exhaust in order to create or maintain a vacuum.

Pfeiffer Design

The turbomolecular pump was developed and patented at Pfeiffer Vacuum in 1958 by Dr. W. Becker. Turbomolecular pumps belong to the category of kinetic vacuum pumps. Their design is similar to that of a turbine. A multi-stage, turbine-like rotor with bladed disks rotates in a housing. The blades of a turbine or a compressor are referred to collectively as the blading. Interposed mirror-invertedly between the rotor disks are bladed stator disks having similar geometries.


Mounting the shaft of a turbopump rotor by means of two ball bearings requires arrangement of both bearings on the fore-vacuum side due to the lubricants in the bearings. This results in a unilateral (cantilever) support of the rotor with its large mass.

Hybrid bearing support offers advantages in this regard with respect to rotor dynamics. Hybrid bearing designates the use of two bearing concepts in one single pump. In this case, an oil-lubricated ball bearing is mounted on the end of the shaft on the fore-vacuum side, and the high vacuum side is equipped with a maintenance-free and wear-free permanent magnetic bearing that centers the rotor radially. The oil for lubricating the fore-vacuum side bearing is contained in an operating fluid reservoir. A small dry safety bearing is arranged within the magnetic bearing stator. During normal operation, a journal rotates freely within this bearing. In the event of strong radial shocks, the safety bearing stabilizes the rotor and rotates only briefly. If the rotor is out of balance, the bearings on both ends of the shaft will generate significantly lower bearing-stressing vibration forces than in the case of a floating bearing. The magnetic bearing on the high vacuum side is totally insensitive to vibration. Only very small vibration forces are transferred to the housing as a result. Moreover, this eliminates the need for the larger of the two bearings in a cantilever concept, whose size limits rotational speed.

Large pumps from a flange diameter of 100 mm alternatively use bearings known as 5-axis magnetic bearings [24]. The rotor is levitated through digital electronic control via distance sensors and electromagnets. The degrees of freedom of the movement of a turborotor are continuously monitored and readjusted in real time. The absence of mechanical contact between the rotor and housing keeps the vibration generated by the pump low. The rotor revolves around its own axis of inertia. Any imbalance due to one-sided coating or erosion (such as in plasma etching) is counteracted within broad limits.

In addition to the absence of oil on the backing-vacuum side, freedom from wear and maintenance is another advantage. In the event of a power failure, the magnetic bearings are supplied with electricity through the rotational energy of the pump. This enables power failures to be easily bridged for several minutes. Should the power failure be of longer duration, the rotor will safely come to a stop at a very low speed through the use of an integrated safety bearing. During system malfunctions, the safety bearing shuts down the rotor to avoid any damage to the pump.

Motors / Drives

Brushless DC motors that afford rotational frequencies of up to 1,500 Hz (90,000 rpm) are used to drive the rotors. This enables the blade velocities that are necessary for pumping the gases.

Today, the drives are typically attached directly to the pumps. The power supply is with 24, 48 or 72 volt direct current, generated by external power supply packs or ones that are integrated in the electronic unit of the pump.


Degrees of freedom of a turbo-rotor


Figure : Degrees of freedom of a turbo-rotor

What are "hybrid" turbomolecular pumps ?

Because turbomolecular pumps only work in molecular flow conditions, a pure turbomolecular pump will require a very large backing pump to work effectively. "hybrid" pumps combine the turbomolecular pump with a molecular drag stage such as a Holweck or Gaede mechanism near the exhaust to reduce the size of backing pump required.

Ball bearings or magnetic levitated ?

A turbo pump's high rotational speeds (some small diameter units operate at 60,000 rpm) put serious strain on the shaft bearings. Most manufacturers now offer light-weight ceramic ball bearings with grease lubrication since this combination is both light, lowering the momentum of the bearing, and has a low bearing-lubricant vapor pressure at the pump's working temperature. More recently, manufacturers have begun offering magnetically levitated bearings which are either permanent magnets for the small sized pumps or a combination of permanent and dynamic magnetic fields, supporting the shaft without contact. Magnetically levitated pumps (such as those manufactured by Shimadzu) include non-contact bearings, resulting in a turbo pump that has true zero oil-vapor backstreaming with bearings that never wear down.
